Shipping Container Framing Bracket
This framing bracket for shipping containers provides a strong 8mm thick steel bracket arm, which extends out from the container corner casting by 110mm when oriented horizontally, and 160mm when oriented vertically.
The bracket is especially suited to attaching exterior frames to a shipping container, since it is able to attach structural timbers to a container both horizontally and vertically.
It can also be used as a fixing point for lean-to structures, to attach a vertical post, or to mount other structures to your shipping container, always in combination with a Domino Clamp.
The framing bracket can be used on its own or in pairs; up to two brackets can be attached to each Domino Clamp for additional strength and support.
Key-Features
▶ Five holes, several orientations, countless uses
▶ Attaches exterior frames and vertical posts for awnings and other structures
▶ Mechanical support, no welding or drilling required
▶ Supplied with bolts and washers for attaching to the Domino Clamp
▶ Hot-Dip galvanised to EN ISO 1461 for superior corrosion resistance
Technical Specifications - Framing Bracket for Shipping Containers
| Plate steel dimensions: | 50mm x 8mm flatbar (see graphic for details) |
| Bracket arm length: | 110mm / 160mm |
| Compatibility: | Compatible with standard M12 threads on Domino Clamps |
| Corrosion resistance: | EN ISO 1461 Hot-dip galvanised finish for superior corrosion resistance |
| Additional Hardware: | Includes M12x25mm set screws and washers required for attaching it to the Domino Clamp. *Domino Clamp required. |
